Basic Info.
Shape
U
Package
100PCS/Bag
Transport Package
Carton
Specification
SV1.25-3
Trademark
Tzeje
Origin
Wenzhou City
HS Code
853690
Production Capacity
50, 000, 000 PCS/Month
Product Description
About Products
1. Products Name: Insulated Ring Terminal
2. Material: Brass or Copper
3. Insulating Tube: PVC/NYLON
4. Packing: 100pcs/bag, inner box and export carton
5. Color: Red/Blue/Black/Yellow as customer required
| Item No | USA Bole No. | Bolt dia d2(mm) | B | F | L | H | DΦ | Color | Description |
| SV1.25-3 | #4 | 3.2 | 5.7 | 6.5 | 21.2 | 10.0 | 4.3 | RED | Lead Section: 0.5~1.5mm² A.W.G.:22~16 Max. Current: 19A Material: Copper/Brass Insulation: PVC |
| SV1.25-3.5S | #6 | 3.7 | 5.7 | 6.5 | 21.2 | ||||
| SV1.25-3.5L | #6 | 3.7 | 6.4 | 6.5 | 21.2 | ||||
| SV1.25-4S | #8 | 4.3 | 6.4 | 6.5 | 21.2 | ||||
| SV1.25-4M | #8 | 4.3 | 7.2 | 6.5 | 21.2 | ||||
| SV1.25-4L | #8 | 4.3 | 8.1 | 6.5 | 21.2 | ||||
| SV1.25-5S | #10 | 5.3 | 8.0 | 6.5 | 21.2 | ||||
| SV1.25-5L | #10 | 5.3 | 9.5 | 6.5 | 21.2 | ||||
| SV1.25-6S | 1/4 | 6.5 | 9.5 | 6.5 | 21.2 | ||||
| SV1.25-6L | 1/4 | 6.5 | 9.5 | 6.5 | 21.2 | ||||
| SV1.25-8 | 5/16 | 8.5 | 14.0 | 12.0 | 29.2 | ||||
| SV2-3 | #4 | 3.2 | 5.7 | 6.5 | 21.2 | 10.0 | 4.9 | BLUE | Lead Section: 1.5~2.5mm² A.W.G.:16~14 Max. Current: 27A Material: Copper/Brass Insulation: PVC |
| SV2-3.5S | #6 | 3.7 | 5.7 | 6.5 | 21.2 | ||||
| SV2-3.5L | #6 | 3.7 | 6.4 | 6.5 | 21.2 | ||||
| SV2-4S | #8 | 4.3 | 6.4 | 6.5 | 21.2 | ||||
| SV2-4M | #8 | 4.3 | 7.2 | 6.5 | 21.2 | ||||
| SV2-4L | #8 | 4.3 | 8.1 | 6.5 | 21.2 | ||||
| SV2-5S | #10 | 5.3 | 8.1 | 6.5 | 21.2 | ||||
| SV2-5L | #10 | 5.3 | 9.5 | 6.5 | 21.2 | ||||
| SV2-6S | 1/4 | 6.5 | 9.5 | 6.5 | 21.2 | ||||
| SV2-6L | 1/4 | 6.5 | 12.0 | 11.0 | 27.2 | ||||
| SV2-8 | 5/16 | 8.5 | 14.0 | 12.5 | 29.2 | ||||
| SV3.5-3.5 | #6 | 3.7 | 8.0 | 7.0 | 25.3 | 13.0 | 6.3 | BLACK | Lead Section: 2.5~4mm² A.W.G.:14~12 Max. Current: 37A Material: Copper/Brass Insulation: PVC |
| SV3.5-4 | #8 | 4.3 | 8.0 | 7.0 | 25.3 | ||||
| SV3.5-5S | #10 | 5.3 | 8.0 | 7.0 | 25.3 | ||||
| SV3.5-6S | 1/4 | 6.5 | 9.0 | 7.5 | 26.5 | ||||
| SV3.5-6 | 1/4 | 6.5 | 12.0 | 12.1 | 28.5 | ||||
| SV5.5-3.5 | #6 | 3.7 | 8.3 | 7.5 | 26.5 | 13.0 | 6.7 | YELLOW | Lead Section: 4~6mm² A.W.G.:12~10 Max. Current: 48A Material: Copper/Brass Insulation: PVC |
| SV5.5-4S | #8 | 4.3 | 8.3 | 7.5 | 26.5 | ||||
| SV5.5-4L | #8 | 4.3 | 9.0 | 7.5 | 26.5 | ||||
| SV5.5-5 | #10 | 5.3 | 9.0 | 7.5 | 26.5 | ||||
| SV5.5-6S | 1/4 | 6.5 | 9.0 | 7.5 | 26.5 | ||||
| SV5.5-6L | 1/4 | 6.5 | 12.0 | 12.0 | 32.5 | ||||
| SV5.5-8 | 5/16 | 8.5 | 14.0 | 11.5 | 31.5 |
