3 Pin 5mm Pitch PCB Screw Mount Type Terminal Block Connector

Shop our 3 Pin 5mm Pitch PCB Screw Mount Type Terminal Block Connector. As a factory, we offer high-quality products at competitive prices. Buy now!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • Product Details
  • Recommand Product
  • Company Profile
  • FAQ
Overview

Basic Info.

Character
Environmental Protection
Production Process
Injection Molding
Interface Type
SATA/ATA
Brand
Golden Electric /OEM
Pitch
5.0mm
Product Name
Pluggable Terminal Blocks
Connection Method
Screw Connection
Description
Screw Terminal Blocks
Rated Voltage
300V
Wire Range
22-14AWG
Rated Current
15A
Model Type
Plug-in Block Connector
Pins
Brass, Tin Plate
Transport Package
Standara Export Carton
Specification
2P/3P/4P~24P
Trademark
Golden or netural, or customer brand
Origin
China
HS Code
8536901900
Production Capacity
20000PCS/Month

Product Description

Product Description



Terminal blocks are classified based on characteristics such structure,device type, and termination options. We can provide pluggable terminal block, PCB Screw terminal block, Barrier Terminal Block and so on.

PCB Screw terminal blocks work by inserting bare wires into the module where a clamp secures the wire in the housing. The housing is then soldered to a PCB in common footprints. PCB mount terminal blocks can be single, dual, or multi-level modules.

Terminal blocks come available in three common orientations: horizontal, vertical, and 45°. Horizontal and vertical are also known as 90° and 180°, respectively. The wire orientation can often be determined by physical restrictions in the overall design that make one option more feasible than the other.


Terminal block is a set of two or more similar screw-down connection points. You can connect wires at these points. A terminal strip combines many similar blocks in a single device. In a strip, the blocks are insulated from one another.


Terminal block's main functions are to connect and to insulate. The main block body is made of plastic, The conducting parts are made of copper.

Terminal block must first be mounted in a safe, stable location away from moisture.You then insert the bare wires into the block's metal connectors and screw them down until they're securely fastened.




Product Parameters



Rated Voltage 300V
Rated Current 15A
Contact resistance 20mΩ
Insulation resistance 5000MΩ/1000V
Withstanding Voltage AC1500V/1Min
Wire range 22~14A WG/2.5mm²
Pitch 5.0mm
Poles 3P
Screws M2.5 steel Zinc plated
Contact phosphor bronze Ni plated or stainless steel
Pin header Brass,Tin plated
Housing PBT,UL94V-0
Temp.Range 30ºC~ + 120ºC
MAX Soldering +250ºC for 5 Sec.
Torque 0.5Nm(3.6lb.in)
Strip length 4. 5- 5mm
